Description

• Camera
• Image Sensor

  [Bullet channel]

  1/2.8 Progressive Scan CMOS

  [PTZ channel]

  1/2.8 Progressive Scan CMOS”

• Min. Illumination

  [Bullet channel]

  Color: 0.005 Lux @ (F2.0, AGC ON), B/W: 0.005 Lux @ (F2.0, AGC ON), 0 Lux with IR

  [PTZ channel]

  Color: 0.005 Lux @ (F2.0, AGC ON), B/W: 0.005 Lux @ (F2.0, AGC ON), 0 lux with IR

• Shutter Speed1 s to 1/30,000 s
• Slow ShutterYes
• Day & NightICR
• Max. Resolution[Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440

• Lens
• Focal Length[Panoramic channel] 2.8 mm, [PTZ channel] 8 mm
• FOV

  [Panoramic channel]

  horizontal field of view: 94°, vertical field of view: 49°, diagonal field of view: 114°,

  [PTZ channel]

  horizontal field of view: 44°, vertical field of view: 24°, diagonal field of view: 51°

• Aperture[Bullet channel] F1.6, [PTZ channel] F1.6

• Illuminator
• Supplement Light Type[Bullet channel] Hybrid (IR and White Light), [PTZ channel] Hybrid (IR and White Light)
• Smart Supplement LightYes
• Supplement Light Range[Bullet channel]: up to 30 m, [PTZ channel]: up to 30 m

• PTZ
• Movement Range (Pan)[Panoramic channel] 0° to 355°, [PTZ channel] 0° to 345°
• Movement Range (Tilt)[Bullet channel] 7° to 17° (manually adjust), [PTZ channel] 0° to 80°
• Pan SpeedPan speed: configurable from 4° to 25°/s, preset speed: 25°/s
• Tilt SpeedTilt speed: configurable from 4° to 20°/s, preset speed 20°/s
• Presets300
• Power-off MemoryYes

• Video
• Scalable Video Coding (SVC)Yes
• Region of Interest (ROI)1 fixed region for main stream
• Main Stream

  [Bullet channel]

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

  [PTZ channel]

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

• Sub-Stream

  [Bullet channel]

  50 Hz: 25 fps (640 × 480, 640 × 360)

  60 Hz: 30 fps (640 × 480, 640 × 360)

  [PTZ channel]

  50 Hz: 25 fps (640 × 480, 640 × 360)

  60 Hz: 30 fps (640 × 480, 640 × 360)

• Video Compression

  Main stream: H.265/H.264/Smart264/Smart265,

  Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate32 Kbps to 4 Mbps
• H.264 TypeBaseline profile,Main profile,High profile
• H.265 TypeMain profile

• Audio
• Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
• Audio Bit Rate64 Kbps(G.711ulaw/G.711alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 160 Kbps(MP2L2)/16 to 64Kbps(AAC-LC)/8 to 160 Kbps(MP3)/8 to 48 Kbps(PCM)
• Audio Sampling Rate8 kHz/16 kHz
• Environment Noise FilteringYes

• Network
• APIONVIF (Profile S, Profile G, Profile T),ISAPI,SDK
• SecurityAuthenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter
• ProtocolsTCP/IP, SMTP, RTSP, FTP, WebSockets, IGMP, WebSocket, Qos, RTCP, HTTPS, PPPoE, SNMP, NTP, RTP, UDP, DNS, HTTP, DHCP, Bonjour, 802.1x, IPv4, IPv6, DDNS, ICMP, UPnP
• Simultaneous Live ViewUp to 6 channels
• User/HostUp to 32 users. 3 user levels: administrator, operator, and user
• ClientiVMS-4200,HiLookVision
• Web BrowserChrome 31 to 44, Firefox 30 to 51, Safari 8.0+

• Image
• Image SettingsSaturation, brightness, contrast, sharpness
• Wide Dynamic Range (WDR)Digital WDR
• SNR≥ 52 dB
• Day/Night SwitchDay,night,auto,schedule
• Image EnhancementBLC,HLC,3D DNR
• Privacy Mask[Bullet channel] 4 programmable polygon privacy masks, [PTZ channel] 4 programmable polygon privacy masks
• Image Parameters SwitchYes

• Interface
• Ethernet Interface1 RJ45 10 M/100M self-adaptive Ethernet port
• On-board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
• ResetYes

• Event
• Basic EventMotion detection (support alarm triggering by specified target types (human and vehicle)), exception
• LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,audible warning

• General
• MaterialPC
• General FunctionMirror,password protection,watermark,IP address filter
• Power

  12 VDC ± 25%, 1.5 A, max. 18 W, Ø5.5 mm coaxial power plug, reverse polarity protection,

  PoE: IEEE 802.3at, Class 4, max. 21.5 W

• Operating Condition-30 °C to 50 °C (-22 °F to 122 °F). Humidity 95% or less (non-condensing)
• Dimension134 mm × 213.5 mm × 291.7 mm (5.3″ × 8.4″ × 11.5″)

• Weight: 1000 g (2.2 lb.)

  With Package Weight: 1500 g (3.3 lb.)

• Approval
• ProtectionIP66 Standard, Surge Protection and Voltage Transient Protection
