Description
Highlight Features
A professional wireless router for small size businesses.
Easy to set up the whole network with all-in-one wireless router.
Press button, Reyee Mesh networking done.
Decent design, flexible installation on desktop and wall.
Securely monitoring the NVR/IPC/internal server anytime from anywhere.
3 Year warranty as standard
Hardware Specifications
Port Specifications
Number of 10/100/1000BASE-T ports
- 5
Number of fixed LAN ports
- 1
Number of fixed WAN ports
- 1
System Specifications
CPU
- Dual-core processor, 880 MHz clock frequency
Flash memory
- 32 MB SPI NOR Flash
RAM
- 256 MB DDR3
Wi-Fi Radio
Wi-Fi standard
- Wi-Fi 5 (IEEE 802.11ac) standard, compatible with IEEE 802.11a/b/g/n standards
Maximum wireless data rate
- 1266 Mbps
Dimensions and Weight
Product dimensions (W x D x H)
- 120 mm x 28 mm x 120 mm (4.72 in. x 1.1 in. x 4.72 in.) (excluding the mounting bracket)
Weight
- 0.251 kg (0.55 lbs.) (without packaging materials)
Environment and Reliability
Mounting options
- Desk, wall
Operating temperature
- 0°C to 40°C (32°F to 104°F)
Software Specifications
System Performance Capacity
Recommended number of concurrent clients
- 150
Throughput
- 700 Mbps
