Integrated services on a single fibre SAT-IF distribution over fibre optics (FO) can supply many households over larger distances, with feed from a central satellite dish station. Almost lossless transmission of satellite, DVB-T and DAB signals. Attenuation per 1000 m only about 0.3 dB. Future-proof and widest possible variety of channels. Space-saving installation - a 3 mm optical fibre replaces five 7 mm coaxial cables. TOST - TRIAX Optical Satellite Transmitter is the core component on headend side of the TOF (Triax Optical Fibre) system. This unit converts RF Wideband or Quatro SAT-IF for transmission over a PON (Passive Optical Network). The transmitter is an installer friendly plug-and-play solution thanks to built-in Automatic Gain Control (AGC) and Automatic Slope Control (ASC) of the RF inputs. The TOST consists of two separate optical transmitters 1310 and 1330nm for wideband SAT-IF LOW and HIGH bands. They are combined to a WDM signal at the TOST output for transmission over single mode fibre cabling. The optical output signal of this headend unit can drive up to 64 optical splits directly. Up to 128 splits can be deployed when using the TWOC optical wideband receivers. Please order mains PSU adapter separately, preferred 18V/2A (318166).

Integrated services on a Single fibre SAT IF distribution over fibre optics (FO) can supply many households over larger distances, with feed from a central satellite dish station. Almost lossless transmission of satellite, DVB-T and DAB signals. Attenuation per 1000 m only about 0.3 dB. Future-proof and widest possible variety of channels. Vertical and Horizontal Wideband IF signals are transmitted over one optical fibre using a Wideband LNB. Space-saving installation - a 3 mm optical fibre replaces five 7 mm coaxial cables. The TWCT has 2 Wideband outputs, Vertical and Horizontal and a separate Terrestrial output
